- 1.
A hair care appliance (10, 500) comprising: a body (30, 530); a handle (20, 520) having a first end (22, 522) in fluid communication with the body (30, 530) and a second end (24) comprising a primary fluid inlet (40, 540) into the appliance; wherein the primary fluid inlet (40, 540) comprises a first aperture (42, 544) extending at least partially around the handle (20, 520) and a second aperture (44, 546) extending through the second end (24) of the handle (20, 520); wherein the handle (20, 520) comprises a wall (220, 560) and the primary fluid flow path extends from the primary fluid inlet (40, 540) within the wall (220, 560) to a primary fluid outlet (440); the handle (20, 520) further comprises a fan unit (70) for drawing fluid in through the primary fluid inlet (40, 540); the handle (20, 520) comprises an outer wall (200, 526) wherein said outer wall (200, 526) extends around the wall (220, 560) and at least partially
along the wall (220, 560)along the wall (220, 560); characterised in that the wall (220, 560) comprises an access aperture for allowing an access to the inside of the wall (220, 560) and a hatch for closing the access aperture. - 2.
An appliance according to claim 1, wherein the handle comprises an end wall (210, 510) at the second end and the second aperture extends through the end wall.
- 3.
An appliance according to claim 1 or claim 2, wherein the first aperture (42, 544) is adjacent the second end of the handle.
- 4.
An appliance according to any preceding claim, wherein the first aperture (42, 544) comprises a plurality of apertures extending at least partially around the handle.
- 5.
An appliance according to any preceding claim, wherein the first aperture (42, 544) comprises a plurality of apertures extending at least partially along the handle.
- 6.
An appliance according to any preceding claim, wherein the plurality of apertures extend radially around the handle and along the outer wall (200, 526) of the handle from the handle end.
- 7.
An appliance according to any preceding claim, wherein a primary fluid flow path (400, 550) is provided from the primary fluid inlet (40, 540) through the handle and into the body to a primary fluid outlet (440, 534).
- 8.
An appliance according to any preceding claim, wherein the wall (220, 560) of the handle is connected to the body at the first end (22, 522).
- 75PCB
- 75afirst board of the PCB
- 75bsecond board of the PCB
- 77larger PCB components
- 80heater
- 300fluid flow path through the body
- 310duct
- 350side wall
- 700flow plate
- 710curved section
- 740slots in the flow plate
The present invention relates to a hand held appliance, and in particular to a hair care appliance such as a hairdryer (10) comprising a body (30) and a handle (20), in which air is drawn into the appliance through a primary fluid inlet (40) at the second end (24) of the handle (20), as shown in Fig. 4a.
In a conventional hairdryer a motor and fan draw air into the body through an inlet at its back end, usually behind a filter. When the appliance is put down on a soft surface such as bedding, that inlet can be covered and the motor can overheat.
CN 202774786 U describes a rotary electric air comb whose handle houses a motor driving a fan, with an air inlet cover at the end of the handle. In CN 201328477 Y the blower of a hairdryer sits at the bottom end of the handle, so that air enters there and passes through the handle into a longer air duct. DE 2618819 A1 describes a cylindrical hairdryer in which an axial fan at the rear of the housing draws air in through openings in an end cover that also carries the cable entry.
Each of these appliances draws air in at the end of the handle or housing, with the fan behind that inlet. The handle then houses the fan unit (70) and its wiring, and in a conventional clam shell construction its two halves are screwed together, so that a user can remove the screws and reach the heater and the fan unit.
There is therefore a need for a handle whose inner wall (220) can be formed in one piece with the body (30), while the components inside it remain accessible during assembly through an opening that can be closed.
